AS568 Standard Silicone Gaskets
AS568 standard-size silicone gaskets from ZSR Silicone match the same inch-size dash system as AS568 O-rings. Use them in groove-based static sealing where a flat gasket profile is preferred over a round O-ring.
FDA 21 CFR 177.2600
Rubber Articles Intended for Repeated Use
LFGB 30&31
EU Food Contact Materials
USP Class VI / ISO 10993
Biocompatibility of Medical Devices
RoHS / REACH
Environmental Compliance
UL 94
Flammability of Plastic Materials
Built to Your Exact Spec
Custom Silicone Gaskets Options
| Image | Product | Type | Short Info | Action |
|---|---|---|---|---|
 | DIN 32676 Silicone Gasket | Standard & Size | DIN 32676 tri-clamp silicone gaskets, FDA food grade, full size range in stock at ZSR factory. | View Details |
 | AS568 Standard Silicone Gaskets | Standard & Size | AS568 standard-size silicone gaskets for groove-based sealing applications. | View Details |
 | DIN 3869 Silicone Sealing Ring | Standard & Size | DIN 3869 profile sealing rings in silicone for hydraulic ports, working from -60°C to +200°C. | View Details |
 | EN 1514-1 Silicone Gasket | Standard & Size | EN 1514-1 silicone flat gaskets for PN flanges, IBC and FF types, standard and custom sizes. | View Details |
 | Custom Die Cut Silicone Gaskets | Standard & Size | Flat silicone gaskets cut to any shape from sheet stock. Precision cutting for exact fits. | View Details |
 | ISO 7483 Silicone Gasket | Standard & Size | Silicone gaskets to ISO 7483 for ISO 7005 flanges, made for international projects and tenders. | View Details |
 | Custom Molded Silicone Gaskets | Standard & Size | Three-dimensional silicone gaskets made by compression or injection molding. For complex sealing shapes. | View Details |
 | ISO 1127 Silicone Gasket | Standard & Size | Sanitary silicone gaskets matched to ISO 1127 stainless steel tube sizes for food and pharma lines. | View Details |
 | Standard Flange Silicone Gaskets | Standard & Size | Silicone gaskets cut to fit pipe flanges. Matches ANSI, DIN and JIS bolt patterns. | View Details |
 | B16.21 Silicone Gasket | Standard & Size | ZSR makes silicone gaskets to ASME B16.21, ring type and full face type, for Class 150 to 2500 pipe flanges. | View Details |
 | ISO 2852 Silicone Gasket | Standard & Size | ISO 2852 silicone clamp gaskets for food industry couplings, FDA grade, factory direct from ZSR. | View Details |
 | Tri-Clamp / Sanitary Silicone Gaskets | Standard & Size | Hygienic silicone gaskets for food and pharmaceutical pipe connections. CIP and SIP compatible. | View Details |
 | B16.5 Silicone Gasket | Standard & Size | Silicone gaskets from ZSR sized to fit ASME B16.5 flanges, NPS 1/2 to 24 inch, Class 150 to 2500. | View Details |
 | Metric Size Silicone Gaskets | Standard & Size | Metric dimension silicone gaskets for international equipment standards. | View Details |
 | DIN 7603 Silicone Sealing Ring | Standard & Size | Flat silicone sealing rings made to DIN 7603 for screw plugs, banjo bolts and threaded fittings. | View Details |
 | DIN 2690 Silicone Gasket | Standard & Size | Silicone flat gaskets to DIN 2690 / EN 1514-1 dimensions for PN6 to PN40 flanges, food grade available. | View Details |
 | DIN 2691 Silicone Gasket | Standard & Size | Silicone gaskets made to DIN 2691 for tongue and groove flanges PN10 to PN160, ideal for plant repair. | View Details |
 | DIN 11851 Silicone Gasket | Standard & Size | Food grade silicone gaskets for DIN 11851 sanitary unions, DN10 to DN150, FDA material. | View Details |
 | FDA Food Grade Silicone Gasket | Grade | Food-safe silicone gaskets for processing equipment. FDA-compliant and taste-neutral. | View Details |
 | Medical Grade Silicone Gasket | Grade | Biocompatible silicone gaskets for medical devices. Sterilizable with full documentation. | View Details |
 | Industrial Grade Silicone Gasket | Grade | General-purpose silicone gaskets for industrial sealing. Reliable, durable and cost-effective. | View Details |
 | High Temperature / Heat Resistant Silicone Gaskets | Special Function | Heat-resistant silicone gaskets rated for continuous use above 200°C. For ovens and furnaces. | View Details |
 | Flame Retardant Silicone Gaskets | Special Function | Self-extinguishing silicone gaskets meeting UL 94 V-0. For fire-safety applications. | View Details |
 | Solid Silicone Rubber Gaskets | Materials | Solid silicone rubber gaskets with excellent compression set resistance and long service life. | View Details |
 | Fluorosilicone (FVMQ) Gaskets | Materials | Fuel and solvent-resistant silicone gaskets for chemical processing and automotive applications. | View Details |
 | Transparent / Clear Silicone Gaskets | Color | Clear silicone gaskets for visible sealing and light-transmitting applications. | View Details |
 | Black / White Silicone Gaskets | Color | Standard black and white silicone gaskets. Fastest delivery from stock. | View Details |
AS568 Size System Applied to Gaskets
AS568 is the American aerospace size standard for O-rings. It is not a gasket standard — but in real projects, its inner diameters (ID) and cross-sections (CS) are widely used as a ready-made size reference for small circular gaskets, washer-style gaskets, and gland seals. The reason is simple: the sizes are fixed, published, and known by engineers everywhere. If your groove was designed for an AS568 size, a gasket made to the same ID and CS will fit right in.
At ZSR Silicone Parts, we make AS568-size gaskets in two basic forms: with a flat cross-section (washer style, cut from sheet) or a round cross-section (O-ring style, molded or cut from cord).
Condensed Reference Table — Popular AS568 Sizes Used as Gaskets:
Dash No. | ID (in) | CS (in) | ID (mm) | CS (mm) |
|---|---|---|---|---|
-006 | 0.114 | 0.070 | 2.90 | 1.78 |
-010 | 0.239 | 0.070 | 6.07 | 1.78 |
-014 | 0.489 | 0.070 | 12.42 | 1.78 |
-020 | 0.864 | 0.070 | 21.95 | 1.78 |
-030 | 1.614 | 0.070 | 41.00 | 1.78 |
-110 | 0.362 | 0.103 | 9.19 | 2.62 |
-113 | 0.549 | 0.103 | 13.94 | 2.62 |
-120 | 0.987 | 0.103 | 25.07 | 2.62 |
-130 | 1.612 | 0.103 | 40.94 | 2.62 |
-210 | 0.734 | 0.139 | 18.64 | 3.53 |
-214 | 0.984 | 0.139 | 24.99 | 3.53 |
-222 | 1.421 | 0.139 | 36.09 | 3.53 |
-226 | 1.984 | 0.139 | 50.39 | 3.53 |
-316 | 0.850 | 0.210 | 21.59 | 5.33 |
-325 | 1.475 | 0.210 | 37.47 | 5.33 |
-360 | 5.850 | 0.210 | 148.59 | 5.33 |
-425 | 4.475 | 0.275 | 113.67 | 6.99 |
-461 | 15.955 | 0.275 | 405.26 | 6.99 |
-475 | 25.940 | 0.275 | 658.88 | 6.99 |
This table shows the most requested sizes. The full AS568 system covers 369 sizes in five cross-section groups — from dash -001 up to -475. Any size in the system is available: tell us the dash number, and we take it from there. For flat washer-style gaskets, the CS column becomes the thickness you need — and we can also cut any thickness you ask for, not only the standard CS.
Gasket Styles Based on AS568 Dimensions
The same AS568 ID and CS can be made in three different gasket styles. Each style fits a different sealing job:
Style | Cross-Section | How It Seals | Best When |
|---|---|---|---|
Flat Washer Gasket | Flat ring, same ID and OD | Seals on a wide, flat contact area | You need large surface sealing between two flat faces — covers, caps, flanged housings |
O-Ring Profile Gasket | Round | Sits in a groove, seals with squeeze | Your housing has a machined groove — the classic gland seal design |
D-Ring Profile Gasket | Flat on one side, round on the other | Like an O-ring, but the flat side locks it in place | The seal must not twist or rotate during assembly or in slow-turning parts |
Quick guide
Choose the flat washer when there is no groove and you seal two flat surfaces. Choose the round O-ring profile when a groove already exists — it needs the least bolt force to seal. Choose the D-ring when rotation is a risk: the flat base stops the gasket from rolling or twisting, which protects the seal and makes assembly easier.
We make all three styles in silicone, in any AS568 size — and in food grade, medical grade, or high temperature compounds on request.
Common Applications for AS568-Size Gaskets
Because AS568 sizes are standardized, they show up in thousands of products. Typical uses for our AS568-size silicone gaskets include:
The standardization also works in your favor on cost and speed. Because these sizes are fixed, we can often supply from existing molds and tooling, or cut them from sheet stock — no new tooling cost, fast sampling, and quick delivery. For many common dash numbers, prototypes ship in days, not weeks.
What Is an AS568 Standard Silicone Gasket?
An AS568 standard silicone gasket is a sealing gasket made to a size from the AS568 system — the American aerospace standard that fixes the inner diameter and cross-section of 369 standard ring sizes, known by their dash numbers.
Strictly speaking, AS568 is an O-ring standard. But its size system has become a common language for all kinds of small round seals. When an engineer designs a sensor housing, a valve cover, or a connector, the groove is often sized to an AS568 dash number. A gasket made to that same dash number — whether it is a flat washer, a round O-ring profile, or a D-ring — will fit that design perfectly, with no custom drawing needed.
Making these gaskets from silicone adds big advantages. Silicone seals at low force, works from -60°C to over 200°C, and resists UV, ozone, and aging far better than standard rubbers. In food grade or medical grade compounds, the same gasket can go into coffee machines, medical devices, or lab equipment. That is why AS568-size silicone gaskets are the default choice for electronics, instruments, pneumatics, and small equipment of every kind.
At ZSR Silicone Parts, we keep tooling and sheet stock for the most common AS568 sizes, and we can make any dash number in the system — flat, round, or D-profile. Tell us your dash number, the style you need, and your quantity. We will send a quote within 24 hours, and samples of common sizes ship in days.
